TECHNICAL DATA:
CNC Heidenhain Tnc 430
TRAVELS
Longitudinal travel: 3.000 mm
Vertical travel: 2.000 mm
Cross travel: 1.600 mm
Sleeve travel: 800 mm
TABLE
Table dimensions: 1.600 x 2.000 mm
Number of positions: 360.000
Maximum load capacity: 9.000 kg
HEAD AND ROTATION RANGES
Sleeve diameter: 125 mm
Speed ranges: 2
Main engine power: 37 kW
Cone type: ISO 50
ADVANCES
Rapid feed X Y Z: 10.000 mm/min
Rapid feed W: 8.000 mm/min
Work progress: 8.000 mm/min
TOOL CHANGER
Number of tools: 40 places
Max tool diameter: 250 mm
Max tool length: 400 mm
Max tool weight: 30 kg
Tool change time: 12 sec
Year of construction: 2000
The images and technical specifications are provided for illustrative purposes only and do not constitute a contractual element.
